PSA has inspected thousands of tubes using
IRIS. The IRIS probe uses
ultrasonic technology to
inspect each tube through its 360° radius. The result is
highly reliable data used to determine locations of problem
areas.
|
 |
|
IRIS Features:
Clear, easy-to-read digital format
Test 360° of tubes from 1/2" - 3" diameter and up to 100' long
Scan up to 400 tubes per twelve hour shift
Uses 110V power supply
Accurate to within +/- .005" |
Our inspection/condition assessment service package
utilizing IRIS includes
nondestructive testing of
Evaporators |
|
Condenser
Tubes |
|
Heat
Exchanger Tubes |
|
Generating Bank Tubes in Drum Boilers |
and other critical areas inaccessible
via standard test methods.
PSA's engineers deliver a report that confirms pertinent findings and
includes recommendations for short-term solutions and long-term
planning, incorporating vividly colored maps and data distribution
graphs of tested areas.
The report is compatible
with MIDAS™ (Material Integrity Data Acquisition
Software) database software for
managing test information.
Return to the Nondestructive
Testing page.
IRIS
(Internal Rotary Inspection System) is an
